Terminal Units
Terminal Units

Medical Gas Pipeline Systems

Terminal Units

Terminal Units (Sapphire) with probes/ADAptors of 02, N20, Vacuum Gas outlet Points (sapphire type) will accept, retain and release the probe/adaptor by means of quick release mechanism designed for single handed operation. The unit shall have a check valve, which is self-sealing when front fascia of the outlet is removed. The Terminal unit and probe connection shall be non-swivel type. A secondary lock arrangement is also available to keep the outlet in parking position. The outlets are completely non-interchangeable at any level of assembly. This outlet point has only two neoprene.



Product Details

  •     The construction of the wall section is made of extruded aluminum
  •    The extruded aluminum structural lower channel will include a vertical integrate equipment mounting track to support optical track mounted equipment
  •     Optional equipment like I.V. Hook, Infusion pole, utility basket, Monitor tray etc. can be install into the track at any location along the extruded aluminum channel

Related Products

Discover More from This Category

Changeover Unit (Medical Gas Pipeline Systems)
