Technical Specification: -
Conforms to | BS EN 331 : 2015, IS / ISO 7396 : 2016 + A1 : 2017 | ||||
Flow rate @ 4.2 bar (max) | 1500 LPM | ||||
Maximum Pressure | 30 bar | ||||
OD of Stub end | 15 mm (22 mm for Vacuum) | ||||
Length of Stub end | 75 mm each side | ||||
Tighten proof | 50 bar | ||||
Closing / Opening of Valve | 90° (1/4th turn) | ||||
Working Temperature | -20 °C to 60 °C [-4 °F to 140 °F] | ||||
Gases | O2, N2O, AIR 4, AIR 7, CO2, Mixed Gases & Vacuum | ||||
Regulatory Status | Complies with Medical Devices Directive 93/42/EEC and Pressure Equipment Directive 97/23/ EC. | ||||
Overall dimensions (in mm) (L × H × W) | 2 Gas | 3 Gas | 4 Gas | 5 Gas | 6 Gas |
375 × 270 × 142 | 375 × 360 × 142 | 375 × 450 × 142 | 375 × 540 × 142 | 375 × 630 × 142 |
